C/B 5200

Mechanical and electrical modifications to standard modules are available. In addition, Schaefer can design and manufacture fully custom solutions. Let Schaefer be your Custom Power Supply Design Solution Partner.

5000W DC/DC Converters, AC/DC Power Factor Corrected Converters and Power Factor Corrected Battery Chargers. The DC/DC Series boasts 5 DC input ranges of 80-160, 160-320, 320-380, 320-640 and 450-800V with 12 single output voltages ranging from 5VDC to 400VDC. The AC/DC Series offers the same range of output voltages from 3-Phase VAC input. The BP200 Series of Battery Charges provides output voltages ranging from 12VDC to 290VDC.

Max Power: 5000 W


AC Input: 3-Phase 3×200/3×400/3×480


DC Output Voltage: 5-800


19″ Rack/ Module: 4U


Wallmount: Yes


Cooling/Product Features: Fan Cooled
